D’Arc 1800 X 1100 X 470 mm

Disclaimer: Pictures shown are for illustration purposes only

JBT-WHT-DARC180X: Built-in Bathtub

1800
Specifications 1260
B

PMMA PU Green
Sheet Reinforcement 1100 580 930

JWA-WHT-DARCSPX: Side Panel 550
JWA-WHT-DARCFPX: Front Panel B
JWA-CHR-132401: Drain Pipe with Overflow & Filler 730 1630
JWA-CHR-DRNPIPE100: Drain Pipe 100 cm with Overflow
IWA-CHR-ACC00510X: Base Europa Kit
JWA-BLK-FRAME 180x110x47: Powder Coated MS Frame
470

SECTION B-B

Note: Drain pipe/Europa kit are mandatory products for installation of all the bathtubs. Accessories shown in the image are not a part of the product
