INSTANT GAS

Available in 6 litres
The perfect instant water heater for small families

Product Specifications

Details Instant Gas
Volume (L) 06
Rated Gas Supply Pressure (Pa) LPG - 2800
Working Pressure (Mpa) 0.01-1
Thermal Load (Heat Input-kW) 12kW
Three Phase
Warranty 1 Year
Product Dimensions (in mm) Code W H D
W
ING-WHT-LPG006 06 Litres 300 455 120 D

Recommended for Kitchen & Bucket Bath

H

WINTER SUMMER
MIN MAX MAX MIN
GAS WATER

ELENA VERTICAL
(Manual)

Available in 6/10/15/25 litres
The perfect storage water heater for small families

Product Specifications
Details Elena Vertical (Manual)
Volume (L) 6/10/15/25
Rated Wattage 2kW
Voltage / Frequency (V/Hz) 230V/50Hz
Temperature Range 25ºC to 75ºC Three Phase
Working Pressure (Mpa) 0.8
Inlet / Outlet Connection (Inch) 1/2
Warranty 7 Years on Tank W D
4 Years on Heating Element
2 Years on Other Parts
Product Dimensions (in mm) Code W H D
ELM-WHT-V006 6 Litres 288 288 260 H
ELM-WHT-V010 10 Litres 328 328 295
ELM-WHT-V015 15 Litres 385 385 305
ELM-WHT-V025 25 Litres 448 448 345

Recommended for: Kitchen / Bucket Baths / Overhead Showers
